IEEE 802.3af (Power over Ethernet) IEEE 802.3at (High-Power PoE+ Power over Ethernet) IEEE 802.3 (10Base-T Ethernet) IEEE 802.3ab (Gigabit Ethernet) IEEE 802.3u (100Base-TX Fast Ethernet) IEEE 802.3x (flow control, for full duplex mode)Media support: - 100Base-TX Cat5 UTP/STP RJ45, 8 pin- 1000Base-T Cat5e UTP/STP RJ45, 8 pin Ports:- One RJ45 10/100/1000 Mbps input port- One RJ45 10/100/1000 Mbps data and power output port Protection functions:- Short circuit protection for short GND- Overload protection for currents over 0.6 A PoE Pinout: IEEE 802.3af/at Standard Mode A- Pin 1: DC (+)- Pin 2: DC (+)- Pin 3: DC (-)- Pin 6: DC (-) Certifications: FCC Class A, CE, RoHSLED Dual-color power and PoE LEDPower Input: 100 – 240 V AC, 50 – 60 Hz Power consumption: 35 watts (maximum)Environmental Plastic housing Dimensions: 136 (L) x 67 (W) x 34 (H) [mm] / 5.35 (L) x 2.64 (W) x 1.34 (H) [in.] Weight: 0.19 kg (0.42 lbs.) Operating temperature: 0 – 50°C (32 – 122°F) Operating humidity: 5 – 90% RH, non-condensing Storage temperature: -20 – 80°C (-4 – 176°F)Package Contents Gigabit High-Power PoE+ Injector Power cable Instructions

IEEE 802.3 (10Base-T Ethernet) IEEE 802.3ab (Twisted Pair Gigabit Ethernet) IEEE 802.3af (Power over Ethernet) IEEE 802.3at (High-Power PoE+ Power over Ethernet) IEEE 802.3az (Energy Efficient Ethernet EEE) IEEE 802.3u (100Base-TX Fast Ethernet) IEEE 802.3x (flow control for full duplex mode)Media support: - 10Base-T- 100Base-TX- 1000Base-T Packet filter/forwarding rate:- 1,488,000 pps (1000 Mbps)- 148,800 pps (100 Mbps)- 14,880 pps (10 Mbps) MAC address table: 8192 entries Buffer memory: 4.1 MB Backplane speed: 24 Gbps Switch architecture: store and forward MTBF: > 50000 hours Display:- Type: LCD- Resolution: 128 x 64 pixels- Viewing area: 37 x 23 mm (1.69 x 0.9 in.) Pinout RJ45 output ports (Data + Power)- Pin 1: Vport [-]- Pin 2: Vport [-]- Pin 3: Vport [+]- Pin 4: Unused [+]- Pin 5: Unused [+]- Pin 6: Vport [+]- Pin 7: Unused [-]- Pin 8: Unused [-] Certifications: FCC Class A, CE, RoHSLEDs Power PoE Link/activity/speedPower Input: 100 – 240 V AC, 50 – 60 Hz Power consumption: 420 watts (maximum)Physical Metal housing Dimensions: 440 (L) x 232 (W) x 45 (H) [mm] / 17.32 (L) x 9.13 (W) x 1.77 (H) [in] Weight: 4 kg (8.8 lbs.)Environmental Operating temperature: 0 – 40°C (32 – 104°F) Storage temperature: -40 – 70°C (-40 – 158°F) Operating humidity: 10 – 90% RH, non-condensing Storage Humidity: 5 - 90% non-condensingPackage Contents 8-Port Gigabit Ethernet Ultra PoE Switch with 4 Uplink Ports and LCD Screen Power cable User manual 19" mounting brackets

IEEE 802.3 (10Base-T Ethernet) IEEE 802.3ab (Twisted Pair Gigabit Ethernet) IEEE 802.3af (Power over Ethernet) IEEE 802.3at (High-Power PoE+ Power over Ethernet) IEEE 802.3az (Energy Efficient Ethernet EEE) IEEE 802.3u (100Base-TX Fast Ethernet) IEEE 802.3x (flow control for full duplex mode)General Media support:- 10Base-T- 100Base-TX- 1000Base-T Packet filter/forwarding rate:- 1,488,000 pps (1000 Mbps)- 148,800 pps (100 Mbps)- 14,880 pps (10 Mbps) MAC address table: 8192 entries Buffer memory: 2 MB Backplane speed: 16 Gbps Switch architecture: store and forward MTBF: > 50000 hours Display:- Type: LCD- Resolution: 128 x 64 pixels- Viewing area: 37 x 23 mm (1.69 x 0.9 in.) Pinout RJ45 output ports (Data + Power)- Pin 1: Vport [-]- Pin 2: Vport [-]- Pin 3: Vport [+]- Pin 4: Unused [+]- Pin 5: Unused [+]- Pin 6: Vport [+]- Pin 7: Unused [-]- Pin 8: Unused [-] Certifications: FCC Class A, CE, RoHSLEDs Power PoE Link/activity/speedPower Input: 100 – 240 V AC, 50 – 60 Hz Power consumption: 150 watts (maximum)Physical Metal housing Dimensions: 280 (L) x 179 (W) x 44.5 (H) [mm] / 11.02 (L) x 7.05 (W) x 1.75 (H) [in] Weight: 1.8 kg (3.97 lbs.)Environmental Operating temperature: 0 – 40°C (32 – 104°F) Storage temperature: -40 – 70°C (-40 – 158°F) Operating humidity: 10 – 90% RH, non-condensing Storage Humidity: 5 - 90% non-condensingPackage Contents 8-Port Gigabit Ethernet Switch with 4 Ultra PoE Ports and LCD Screen Power cable User manual 19" mounting brackets

1 x 60 W Port, IEEE 802.3bt and IEEE 802.3at/af Compliant, Plastic Housing Save time and money by delivering data and power via existing network cables Power output of up to 60 watts over a four-pair Cat5 or Cat6 network cable Compatible with IEEE 802.3bt (Ultra-PoE), IEEE 802.3at and IEEE 802.3af

IEEE 802.3at/af Power over Ethernet (PoE+/PoE) Compliant, 300 W, Endspan, 19" Rackmount Provides power and data connection for up to 16 PoE network devices Saves time and money by delivering data and power via existing network cables 10/100/1000 auto-sensing ports automatically detect optimal network speeds
